Our entry level lightweight, portable black and white ultrasound scanner is an ideal first system for first opinion small animal vets or equine vets doing basic repro work.
The DP-30 is a compact black and white ultrasound system that will allow you to do much more than just pregnancy scans but at an affordable price.
Scan and make measurements in both B-mode and M-mode. Label up imaging studies with pre-defined or custom annotations. Provided with a wide range of veterinary optimised imaging presets Power Doppler imaging to identify blood flow in the abdomen Wide range of affordable probes for multiple imaging applications Easy review and export images through the intuitive iStation interface
System type (portable/cart) | Portable |
Console form (clam shell/touchscreen) | Flip down |
Number of probe connectors on console | 2 |
Screen Size | 12.1 inch |
Optional trolley | |
Multi-probe compatibility on trolley | |
Colour Doppler | |
Pulse Wave Doppler | |
Continuous Wave Doppler | |
ECG | |
Width (mm) | 290 |
Depth (mm) | 167 |
Height (mm) | 350 |
AED | 5.6 |
Battery included? | Opt |
Battery life (mins) | 100 |
Warranty | 1 year |
Small animal | |
Exotic | |
Equine | |
Bovine |
The DP-30Vet with a single micro-convex probe (DP-65C15 5.0-8.5 MHz 15mm radius) can be used to perform abdominal and cardiac examinations on a wide range of species including dogs, cats, rabbits and reptiles.
The DP-75L50 5.0-10.0 MHz 50mm footprint probe can be used to perform pregnancy scans making this an affordable option for equine repro.
